Apex 570 NEW

Dual operator truck mounted carpet, upholstery and hard surface cleaning system

High performance cleaning and restoration in a new design that will maximise your investment.

With the powerful and reliable liquid-cooled Kubota petrol engine and the proven Gardner Denver TriFlow® Rotary Tri-Lobe vacuum blower, the Apex 570 is ideal for cleaning carpets, hard surfaces and flood extraction. Provides dual-wand capability for larger commercial jobs.

  • Quieter Helical Tri-Lobe HF 408 Blower produces less vibration and ensures better dry times.
  • Through-frame drive belt cooling significantly reduces downtime by extending belt life.
  • Cerakote® ceramic coating on exhaust system minimizes heat and extends components’ service life.
  • Patented thermal well design incorporates tube-and-shell heat exchanger to maximize heat transfer from engine to solution.
  • Easy-to-remove access panel and side hoods allows for quick service.

Description

STANDARD EQUIPMENT
  • Carpet wand 35 cm (14 in.) 6-jet titanium alloy
  • 1 x 30 m (100 ft) 6.3 mm (0.25 in.) pressure hose
  • 1 x 15 m (50 ft) 6.3 mm (0.25 in.) pressure hose
  • 3 x 15 m (50 ft) 50 mm (2 in.) vacuum hose and connectors
  • 1 x 15 m (50 ft) 19 mm (0.75 in.) inlet water hose
  • Complete installation and operator training
  • Operation and service manual

SPECIFICATIONS

Console Dimensions 109 x 127 x 56 cm (h x l x w)
Console weight 464 kilos
Power unit Kubota 31 hp 970cc 3 cylinder liquid-cooled engine
2700 rpm unleaded petrol
Fuel supply Fuel pump and 22 litre tank included
Solution pump General Emperor triple plunger stainless steel
5 gpm 24 -103 bar (350 – 1500 psi)
Solution pressure control fully adjustable
Water supply Automatic fill with optional fresh water tank
and front panel control switch
Chemical pump Stainless steel with automatic metering unit
& chemical flow simulator valve
Heat exchanger 3 stage stainless steel tube coils
110C (230F) with solution temperature control valve
Vacuum Gardner Denver HF408 Tri-flo 13″ Hg 455 cfm
Waste tank 340 litres (automatic shut-off) with optional heavy duty
automatic waste pump-out and front panel control switch

Additional information

Weight 464 kg
